| Type | VRRM(V) | IO(A) | IFSM(A) | VF(V) | VF at IF(A) | IR(uA) | CJ(PF) | Package | 申请样品 |
|---|---|---|---|---|---|---|---|---|---|
| UMB10F-10 | 1000 | 1.0 | 35 | 1.5 | 1 | 5 | 18 | MBF | 申请样品 |
| UMB8F-10 | 800 | 1.0 | 35 | 1.5 | 1 | 5 | 18 | MBF | 申请样品 |
| UMB6F-10 | 600 | 1.0 | 35 | 1.5 | 1 | 5 | 18 | MBF | 申请样品 |
| UMB4F-10 | 400 | 1.0 | 35 | 1.3 | 1 | 5 | 18 | MBF | 申请样品 |
| UMB2F-10 | 200 | 1.0 | 35 | 1.0 | 1 | 5 | 18 | MBF | 申请样品 |
| UMB1F-10 | 100 | 1.0 | 35 | 1.0 | 1 | 5 | 18 | MBF | 申请样品 |
| MSB30M | 1000 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MSB30K | 800 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MSB30J | 600 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MSB30G | 400 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MSB30D | 200 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MSB30B | 100 | 3.0 | 80 | 1.1 | 3 | 5 | 40 | UMSB | 申请样品 |
| MB320S-TN | 200 | 3.0 | 70 | 0.95 | 3 | 300 | 160 | MBS | 申请样品 |
| MB310S-TN | 100 | 3.0 | 70 | 0.85 | 3 | 300 | 160 | MBS | 申请样品 |
| MB220S-TN | 200 | 2.0 | 40 | 0.85 | 2 | 300 | 80 | MBS | 申请样品 |
| MB210S-TN | 100 | 2.0 | 40 | 0.85 | 2 | 300 | 80 | MBS | 申请样品 |
| MB120S-TN | 200 | 1.0 | 30 | 0.9 | 1 | 100 | 80 | MBS | 申请样品 |
| MB115S-TN | 150 | 1.0 | 30 | 0.9 | 1 | 100 | 80 | MBS | 申请样品 |
| MB110S-TN | 100 | 1.0 | 30 | 0.85 | 1 | 200 | 80 | MBS | 申请样品 |
| MB38S-TN | 80 | 3.0 | 70 | 0.85 | 3 | 300 | 160 | MBS | 申请样品 |
